PRODUCT SPECIFICATIONS
ENGINE
- Rated Power: 50 HP
- Aspiration: Naturally
- Maxi Torque: 175,5 NM
- Number of Cylinder: 4
- Fuel Tank Capacity: 36 L
- Air Cleaner: Outside Oil Bath Type
- Fuel Consumption: 6.8 L/h
- ENGINE: Laidong KM495BT
TRANSMISSION
- Driving Type: 4WD
- Clutch: 9 Inch, Dual Function Clutch
- Gearbox: 8+8, Synchronizer with shuttle gear
- PTO Speed: 540/1000
- PTO Gear: 6 Spline
- Front Axle: Lovol
BRAKES
- Driving Brake: Oil Immersed Disc Brakes
- Parking Brake: Mechanical Arm Brake
- Air Brake (Trailer Brake): Optional
Hydraulics
- Lifter Type: Position Control, Floating Adjustment
- 3 Point Linkage: Cat I
- Hydraulic Lifting Capacity at Lift Point: 1250 KG
- Hydraulic Lifting Capacity at 610 mm: 830 KG
- No. of Spool Valves: 2
Cabin or Rops
- Cabin with AC: Optional
- Dimension: Available
Tyre
- Front: 8.3-20
- Rear: 12.4-28
Dimension & Weight
- Dimension: 3667 x 1620 x 2335 mm
- Ground Clearance (Min): 380 mm
- Gross Structure Weight: 1780 KG
- Wheel Base: 1900 mm
