PRODUCT SPECIFICATIONS
ENGINE
- Rated Power: 110 HP
- Aspiration: Turbo + Intercooling
- Maxi Torque: 485 NM
- Number of Cylinder: 4
- Fuel Tank Capacity: 145 L
- Air Cleaner: Wet-type + KleanAire
- Fuel Consumption: 10.8 L/h
- ENGINE: Huafeng 4RMIZT26
TRANSMISSION
- Driving Type: 4WD
- Clutch: Mechanical Dual Clutch of 12 Inch LUK
- Gearbox: Shuttle Collar 16FWD + 8REV
- PTO Speed: 540/1000
- PTO Gear: 6 Splines
- Front Axle: Lovol
BRAKES
- Driving Brake: Hydraulic Oil Immersed Disc Brakes
- Parking Brake: Independent Type
Hydraulics
- Lifter Type: High Pressure Split-type Hydraulic Lifter
- 3 Point Linkage: Cat II
- Hydraulic Lifting Capacity at Lift Point: 3800 KG
- Hydraulic Lifting Capacity at 610 mm: 2000 KG
- No. of Spool Valves: 2
Cabin or Rops
- Cabin with AC: Optional
- ROPS with Sunshade: Available
Tyre
- Front: 12.4-24
- Rear: 18.4-30
Dimension & Weight
- Dimension: 4670 x 2150 x 2900 mm
- Ground Clearance (Min): 405 mm
- Gross Structure Weight: 3860 KG, 4261 (CAB)
- Wheel Base: 2405 mm
