Product Specifications
ENGINE
- Engine Model: YANMAR 4TNV94L
- Rated Power (kW/rpm): 36.2 / 2200
- Max. Torque (N·m/rpm): 212 / 1260
- Displacement (L): 3.054
HYDRAULIC SYSTEM
- Max. Flow (L/min): 151 L/min
- Max. Working Pressure (MPa): 24.5
- Max. Pilot Pressure (MPa): 3.7
- Max. Swing Speed (rpm): 11
- Max. Traveling Speed (km/h): 2.5 / 5.0
- Max. Bucket Digging Force (kN-ISO): 40
- Max. Arm Digging Force (kN-ISO): 28
- Max. Traction Force (kN): 58.3
- Grade Ability: 35°
- Fuel Tank (L): 130
- Ground Pressure (kPa): 31
- Hydraulic Oil Tank (L): 80
OVERALL DIMENSIONS
- Length × Width × Height (mm): 5890 × 2000 × 2590
- Boom Length (mm): 3000
- Arm Length (mm): 1550
- Track Shoe Width / Tire Size (mm): 400
CHASSIS
- Track Shoe Number (each side): 38
- Carrier Rollers Number (each side): 1
- Track Rollers Number (each side): 5
ELECTRIC
- System Voltage (V): 12
- Battery Capacity: 12V, 100Ah
